se:do pro 2
Well-proven ergonomics in a modular system – convincing in price-performance
Modular system
High flexibility in terms of areas of application and users, as individual components can be customised within the modular system.
Comfortable and ergonomic sitting thanks to application-specific mechanisms
Automatic weight system
“Similar” mechanism with weight adjustment and automatic seat tilt up to 5°
• for non-territorial areas of use
• lockable in 4 different positions
• opening angle: 0, 8, 16 and 26°
“Similar” mechanism with weight adjustment and automatic seat tilt up to 5°
• for light users and non-territoria4 Anschlägen feststellbar
• lockable in 4 different positions
• opening angle: 0, 8, 16 and 26°
Individual weight adjustment
“Similar” mechanism with individual weight adjustment, without forward tilt
• for territorial areas of use
• lockable in 3 positions
• opening angle: 26°
Similarmechanik mit individueller Gewichtseinstellung und Sitzneigeverstellung 4°
• for territorial areas of use
• lockable in 3 positions
• opening angle: 26°
Two backrest versions
Fully upholstered
Membrane
Versions and models
Office chair
(5-star base)
Counter chair
(5-star)
Visitor chair
(cantilever chair)
Visitor chair
(4-leg)
Options/accessories
- Lumbar support depth adjustment
Seat depth adjustment (70 and 100 mm) - Retrofittable neck support with coat hanger, as a set
- Project neck support, membrane-covered and retrofittable
- Retrofittable coat hanger
Sustainable production
We purchase around two thirds of the steel, aluminium and wood which we require to produce our products in Germany and almost all the rest from Europe, this helps us to avoid long delivery routes whilst, at the same time, boosting the local economy. We use materials which have been tested and assessed with respect to potentially adverse effects on human health and the environment.
Sustainable production of se:do pro 2
- Covers not glued into place
- CFC-free foams
- Galvanisation with chrome III
- Use of certified upholstery fabrics in accordance with OEKO-TEX Standard 100
- Produced using 100 % green electricity
- Produced in accordance with EMAS III Environmental management
- Produced in accordance with DIN ISO 14001 Environmental management
- Produced in accordance with DIN EN 45001 Occupational safety
Options
| standard | optional | |
|---|---|---|
| Upholstery | Seat upholstered, backrest with membrane cover Seat and backrest upholstered | Different cover for backrest |
| Membrane | Black | Grey, blue, olive green |
| Model colour/plastic parts | Black | |
| Lumbar support | No lumbar support | Lumbar support depth adjustment |
| Armrests | Without armrests | 2D armrests with plastic covers Height-adjustable plastic armrests 3D armrests with plastic covers, width adjustable 3D armrests with PUR covers, width adjustable 4D armrests with soft-touch covers 4D armrests with 360° rotable soft-touch covers |
| Seat | Standard seat | Sliding seat (70 mm adjustment range) |
| Mechanism | Similar mechanism with automatic weight adjustment | Similar mechanism with automatic weight adjustment for light persons Similar mechanism with individuel weight adjustment Similar mechanism with individuel weight adjustment and forward tilt |
| Seat height-adjustment | Gaslift | Sedo-Lift mechanism lll |
| Base | 5-star plastic base, black | 5-star aluminium base, black, wihte aluminium, polished |
| Castors | Hard castors for soft flooring | Soft castors for hard flooring |
| Fire protection | Fire protection vrsion in combination with the cover fabrics Fame, One or Step | |
| Accessories | Coat hanger Neck support with height and tilt adjustment in black imitation leather Neck support with height and tilt adjustment, membrane black, fire restistant Set neck support/coat hanger Model prepared for retrogitting the accessories |
Technical Specifications
| Backrest | – Large, ergonomically shaped backrest, suitable for any body size, plastic frame in the model colour – Membrane version: mesh cover made from self-supporting knitted fabric – Upholstered version: upholstered backrest (moulded foam in PU with Sedus cover fabrics, attached all round without metal by means of sewn-on piping tape), upholstery thickness 55 mm – Height adjustment of backrest 80 mm, optional lumbar support depth adjustment (membrane version 12 mm, upholstered version 25 mm by means of integrated air cushion) – Optional neck support with height and tilt adjustment, covered with black imitation leather or with black mesh – Optional coat-hangers available individually or as a set with neck support |
| Armrests | – Code 3611: height-adjustable plastic armrests – Code 3211: 2D armrests – height- and width-adjustable – Code 3911: 3D armrests with plastic covers, width adjustable without tools – Code 3914: 3D armrests with soft-touch covers, width adjustable without tools – Code 3414: 4D armrests with soft-touch covers, height- and width-adjustable, movable pad, armrest support width adjustment, no tools required – Code 3424: 4D armrests with 360° rotatable soft-touch covers, height- and width-adjustable, movable pad, armrest support width adjustment, no tools required |
| Mechanism | – Synchron mechanism with automatic user weight recognition with smooth force transmission in black – Seat and backrest move completely synchronously with the body – Synchronicity relationship between seat and backrest 1:3,5 – Automatic adaptation to different users‘ body weights, version for light persons available as an option – Backrest tilt mechanism: 34°, locking in foremost position possible or additional restriction of backrest movement at 8, 16 and 26° – Automatic forward tilt (resulting from a shift in the user‘s weight) of up to 5° – Optional, Synchron mechanism with individual weight adjustment in black, backrest tilt mechanism: 30°, locking in 3 positions: in upright, middle and in leaned far back (30°) position, seat can be optionally adjusted by up to 5° in seat inclination for pressure relief in the thighs |
| Seat | – Ergonomically and anatomically shaped 5-zone seat ensures even pressure distribution and long-lasting sitting comfort for any body size – Shaped foam (polyurethane foam) – Foam thickness 45 mm, upholstery thickness 45 mm |
| Seat height-adjustment | – Continuous gas spring height adjustment – Mechanical gas spring: Full suspension of the body weight even in the bottom seat position due to pneumatic locking, practically wear-free, no failure or gas spring replacement |
| Base | – 5-star plastic base or 5-star aluminium base – Hard or soft castors with 65 mm diameter |
| User weight | – Recommended for user weights up to 150 kg |
| Warranty | – 5 years – 30 years for Sedo-Lift mechanism |
